PRODUCT OVERVIEW
VA-QMY202 series is suitable for medium andlong distance shooting. MH-RM series is equipped with 3x objective lens, 5x objective lens and 6x objective lens. In most harsh environments, VA-QMY202 series shows its superiority and accuracy. The battery lasts for a long time, up to 60 hours, equipped with integrated fixtures. VA-QMY202 series applicable to type 95, type 85, type 88, etc.
MAIN FEATURES
Standard Picatinny rail system, lightweight and easy to operate.
Built-in reticle, adjustable objective lens.
No recalibration is required when changing weapons.
It has strong impact resistance and can be used with weapons with heavy rebound.
Military Action
Assisted Driving
Outdoor Camping
Security Monitoring
Predictive Maintenance
Home Security
Search & Rescue
Cave Exploration
Air Patrol
| Model | VA-RM583 |
| Magnification | 3x |
| Field of View | 12° |
| Lens System | 80 mm F/1.6 |
| Focus Range | 10 m to infinity |
| Eye Relief Distance | 45 mm |
| Diopter Setting | +3D, -4D |
| Overall Dimensions | 269 mm* 99 mm* 87 mm |
| Weight | 1120 g |
| Power Supply | 1*CR123 battery, 3V |
| Estimated Battery Life | up to 60 hours |
| Photocathode Type | 18 mm S-25 |
| Photocathode Sensitivity | ≥550 μA/m |
| Resolution | 48-58/57-64 lp/mm |
| Luminous Gain | 19000-25000 fl/fcd |
| Signal-to-Noise Ratio | 20:1 or better |
| FOM | ≥1150 |
| Tube Reliability Standard | 10000 hours |
| Keep Time | 10 years |
| Warranty | One year |
| Detection Range | 200 m - 350 m |
| Recognition Range | 180 m - 220 m |
| 5mW IR Illuminator | up to 100 m |
| Operating Temperature | -35°C to +50°C |
| Storage Temperature | 35°C to +70°C |
For more information, please click the button below to download a PDF of the product.
Downloads
Night Vision Scope QMY202
