Product features
built-in 14/15bitADC, digital output, high quantum efficiency, high dynamic range, high detection sensitivity, metal tube vacuum integrated packaging, working at or near room temperature
Application fields
short-wave infrared imaging, spectral analysis, etc., which can be used for night vision imaging, border inspection and security, military equipment, industrial and agricultural detection, satellite remote sensing, biomedicine, environmental monitoring, etc.
Search & Rescue
Observe Animals
Home Security
Predictive Maintenance
Night Hike
Outdoor Camping
Assisted Driving
Security Monitoring
Hunting
| Effective pixel rate | ≥99.5% |
| Dynamic Range | ≥80dB |
| Spectral response range | 0.9μm-1.7μm |
| Detector specifications and pixel center distance | 1280×1024/10μm |
| Response rate non-uniformity | ≤6% |
| Full frame maximum frame rate | ≥60Hz@4 channels |
| Number of quantization bits | 14bit/15bit |
| Peak quantum efficiency | ≥75%@1550nm |
| Typical peak detection rate | 5×1012cm.√Hz/W |
| Package | Metal vacuum package, built-in TEC, weight 19g |
For more information, please click the button below to download a PDF of the product.
Downloads
InGaAs Short Wave infraredLineScan Detector VA-KIP1212
