The detector type is amorphous silicon uncooled infrared focal plane; four major modes: infrared mode, low light mode, dual light fusion, picture-in-picture mode; image effects: five color palettes of rainbow, iron red, cold color, black hot, and white hot; small size, easy to carry and use, good environmental adaptability; with IP67 protection level, dust and fog proof, suitable for various environments; high-sensitivity CMOS sensor.
Home Security
Observe Animals
Search & Rescue
Security Monitoring
Predictive Maintenance
Military Action
Cave Exploration
Hunting
Outdoor Camping
| Thermal System | |
| Detector Type | UnCooled VOx FPA |
| Resolution | 640 x 512 px |
| Spectral Range | 8 to 14 μm |
| Pixel Pitch | 12μm |
| Frame Rate | 50Hz |
| NETD | ≤40mk |
| Polarity | White-Hot/Black-Hot/Rainbow/Iron/Green etc. |
| Focus Mode | Motorized focus |
| Focus Range | 10m~∞ |
| IR Len | f=75mm,F#1.0 |
| FOV | 5.9°×4.7° |
| E-Zoom | 1~8x |
| Detection Human(1.7×0.5m) | 2800m |
| Detection Vehicle(3.0×1.5m) | 7000m |
| Recognize Human(1.7×0.5m) | 800m |
| Recognize Vehicle(3.0×1.5m) | 2800m |
| CMOS System | |
| Sensor Type | HD CMOS |
| Resolution | 1920×1080 px |
| CMOS Size | ½ inch |
| Unit Cell Size | 3.75μm |
| Lens | f=75mm(Fixed) |
| Frame Rate | 60Hz |
| FOV | 5.5°×3.1° |
| E-Zoom | 1~16x |
| Laser Range Finder | |
| Wavelength | 1535±5nm(Eye Safe,CLASS 1) |
| Range Distance | 3km/5km(opt.)/8km(opt.)/10km(opt.) |
| Accuracy | ±1m |
| Efficiency | >98% |
| Display | |
| Panel | 2×0.39' OLED |
| Resolution | 1024×768 px |
| Eyepiece Magnification | 15× |
| Interface | |
| GPS/GNSS | ≤2.5m(CEP) yes(L1+L5) |
| WiFi | yes |
| Digital Magnetic Compass(Azimuth) | ±1° |
| Digital Magnetic Compass(Pitch) | ±0.5° |
| Photo&Video | yes |
| Storage | EMMC 32GB/64GB |
| Data Transfer | Picture&Video USB2.0 |
| Mount Adaptor | ¼ inch Standard Tripod Mounting |
| Power | |
| Battery | 11.1V 3400mAh(3×18650 Li-ion) |
| Average Power | ≈5.5W |
| Operate Time | ≈5h |
| Environment | |
| Protection Level | IP66 |
| Operating Temperature | -30°~+55° |
| Storage Temperature | -40°~+60°(No condensation) |
| Physical | |
| Dimensions(Length) | 241mm |
| Dimensions(Wide) | 242mm |
| Dimensions(Hight) | 97mm |
| Weight | ≈2.4Kg(including battery) |
